Introduction
Just before the release of Tensorflow 2.0 (mid 2019), developing large and complex deep learning models with Tensorflow 1.x required some understanding of how static graph semantics worked using tf.Session. This usually made machine learning development processes extremely complicated, difficult to explain and understand. Because of this the enthusiasm of new deep learning practitioners excited to learn TF, was reduced to migrating to more friendly or pythonic options such as Keras or PyTorch.
Since Tensorflow 2.0 there are two types of APIs used to build and train deep neural networks. The first and most known is tf.keras which contains a high amount of tutorials and documentation available across the internet (the most known is the official tensorflow documentation), but what if we don’t want to rely on tf.keras development to build and train deep neural networks, but make our own layers, operations and models with native Tensorflow code?
This post explains in detail how to define, build and call layers and models using Tensorflow’s low level API.
Base Neural Networks Class (tf.Module)
As the official tensorflow documentation says, tf.Module is a base class for deep neural networks, quite similar to what we have in PyTorch using nn.Module. If we want to build a new layer/operation or model, we have to subclass tf.Module and initialize all trainable/non-trainable parameters using tf.Variable.
For this example and as a complement to the recent update of the official documentation (which explains clearly how to build a Multilayer Perceptron Network - MLP). We will create a Convolutional Neural Network CNN.
Create a new trainable layer
To start, we need to define our trainable variables (a.k.a weights), to do this we need to initialize them using some initialization method (ex. Normal, Glorot, Xavier, etc). In the case of deep neural networks we are interested in defining and training weights and biases
1 2 3 4 5 6 7 8 9
def weights(name, shape, mean=0.0, stddev=0.02): # for this case I am using a normal distribution var = tf.Variable(tf.random_normal_initializer(mean=mean, stddev=stddev)(shape), name=name) return var def bias(name, shape, constant=0.0): var = tf.Variable(tf.constant_initializer(constant)(shape), name=name) return var
We want to create an object for our new layer, in this case a 2D convolutional layer, in contrast to the official TF docs, we can create the shapes of the weights and biases inferring their shapes directly on the first forward pass
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42
class Conv2D(tf.Module): """ Custom Convolutional layer with explicit padding """ def __init__(self, num_filters, kernel_size=3, padding=1, strides=1, act_type='ReLU', name=None): """ :param: num_filters: Number of filters :param: kernel_size: kernel size :param: padding: explicit padding (0 to not use padding int=>1 to pad input) :param: strides: explicit strides :param: act_type: activation type :param: name: name of the layer """ super(Conv2D, self).__init__(name=name) self.filters = num_filters self.ks = kernel_size self.pad = [[padding] * 2] * 2 self.s = strides self.act_type = act_type def build(self, input_shape): if not hasattr(self, 'weights'): self.weights = weights('weights', (self.ks, self.ks, input_shape[-1], self.filters)) if not hasattr(self, 'bias'): self.bias = bias('bias', (self.filters)) @tf.Module.with_name_scope # keep track of the variables names and their hierarchies def __call__(self, input): # build weights and biases input_shape = input.get_shape() self.build(input_shape) # explicit zero padding and convolution x = tf.pad(input, [[0, 0]] + self.pad + [[0, 0]], constant_values=0) x = tf.nn.conv2d(x, self.weights, strides=[self.s]*4, padding='VALID') x = tf.nn.bias_add(x, self.bias) # activation (in this case only ReLU) x = tf.nn.relu(x) if self.act_type == 'ReLU' else x return x
We can test if the layer implementation is working correctly by calling it and getting its variables (the weight’s tensors):
1 2 3 4 5 6 7 8
# create fake image x = tf.random.uniform((1, 128, 128, 3), dtype=tf.float32) conv = Conv2D(num_filters=4, name='test_conv') conv(x) # forward pass on the layer # then we can print the weights created to verify their values and shapes conv.trainable_variables
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42
(<tf.Variable 'test_conv/bias:0' shape=(4,) dtype=float32, numpy=array([0., 0., 0., 0.], dtype=float32)>, <tf.Variable 'test_conv/weights:0' shape=(3, 3, 3, 4) dtype=float32, numpy= array([[[[ 0.00553657, 0.01345694, 0.0160969 , -0.00974667], [-0.0174912 , -0.00867653, 0.01673212, -0.01981817], [ 0.00546766, -0.00352232, 0.01730617, 0.03613425]], [[-0.02024776, 0.00949733, -0.01584678, -0.0232379 ], [-0.00929332, 0.00113463, -0.00618072, -0.00331176], [ 0.01551097, -0.01571138, 0.01730444, -0.00512385]], [[-0.00026536, 0.02602397, 0.03468624, -0.01000871], [-0.00465783, -0.01016334, 0.01106991, -0.02338664], [-0.00632419, -0.02121128, 0.02255995, -0.00294858]]], [[[ 0.01078237, -0.01998009, -0.01237592, -0.01769269], [ 0.01115903, -0.02444682, -0.02847697, -0.00149765], [ 0.01714881, 0.03219299, 0.00256057, -0.01943027]], [[ 0.03568217, -0.00663988, 0.01306447, -0.02267795], [ 0.00643562, -0.02551239, -0.02827096, -0.02343682], [-0.00941015, -0.00949762, 0.04840184, 0.00754907]], [[-0.00122065, -0.0315739 , -0.01874557, 0.00350243], [-0.02523333, 0.0312549 , -0.00660984, 0.0077161 ], [ 0.01008623, -0.00679884, -0.02994534, 0.00870273]]], [[[ 0.00458873, 0.02161162, -0.00432352, 0.00619686], [ 0.00921444, -0.00113679, -0.01196389, -0.0254667 ], [ 0.0068634 , -0.00199798, 0.04269401, 0.05141414]], [[-0.01473054, -0.02008617, -0.02860904, 0.03205349], [ 0.01996609, -0.00063833, -0.00017963, 0.00412473], [ 0.02097527, 0.03115197, 0.00866693, 0.01411885]], [[ 0.02391446, -0.01629277, 0.02057827, 0.00664399], [ 0.00774666, -0.01262378, -0.0365187 , -0.01844351], [-0.00975288, -0.01222847, 0.00185206, 0.01441888]]]], dtype=float32)>)Have a look on how the name of the weights maintain an order of “name_of_layer/name_of_weight”.
We can also check the size of the output tensor:
1 2
# shapes of the output y.get_shape()
1
TensorShape([1, 128, 128, 4])
Create a model
Once the layers are defined with tf.Module we can write a complete model. In this case a CNN. To do this, we first have to define a couple of common operations used in these type of models, e.g. max-pooling, linear/dense layers, etc.
Starting with max pool (quite similar to what can be expected in tensorflow 1.x but without the name scoping):
1
2
3
4
5
6
7
8
9
10
11
12
def max_pool2d(x, size=2, stride=None, padding='VALID', name=None):
"""
Common max-pooling 2D layer
"""
# Here we are not explicitly padding the input as in the Conv2D
stride = stride or size # if no stride is given use the pool size
x = tf.nn.max_pool2d(x,
ksize=[1, size, size, 1],
strides=[1, stride, stride, 1],
padding=padding,
name=name)
return x
Next, we can refine the Dense layer of the TF documentation a bit with the tweaks of the Conv2D layer defined above as follows:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
class Dense(tf.Module):
def __init__(self, num_outputs, act_type=None, name=None):
super(Dense, self).__init__(name=name)
self.num_outs = num_outputs
self.act_type = act_type
def build(self, input_shape):
if not hasattr(self, 'weights'):
self.weights = weights('weights', shape=(input_shape[-1], self.num_outs))
if not hasattr(self, 'bias'):
self.bias = bias('bias', shape=(self.num_outs))
@tf.Module.with_name_scope
def __call__(self, inputs):
# build weights first call
self.build(inputs.get_shape())
# linear operation
x = tf.matmul(inputs, self.weights) + self.bias
# activations
if self.act_type == 'ReLU':
return tf.nn.relu(x)
elif self.act_type == 'Sigmoid':
return tf.nn.sigmoid(x)
else:
return x
Then we write the final model (using again tf.Module):
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
class CNN(tf.Module):
def __init__(self, name=None):
super(CNN, self).__init__(name=name)
with self.name_scope:
self.conv1 = Conv2D(8, name='C64')
self.conv2 = Conv2D(16,name='C64')
self.conv3 = Conv2D(32,name='C64')
self.conv4 = Conv2D(64,name='C64')
self.out = Dense(1, name='output', act_type='Sigmoid')
@tf.Module.with_name_scope
def __call__(self, input):
x = self.conv1(input)
x = max_pool2d(x)
x = self.conv2(x)
x = max_pool2d(x)
x = self.conv3(x)
x = max_pool2d(x)
x = self.conv4(x)
x = tf.reshape(x, [tf.shape(x)[0], -1]) # flatten op
output = self.out(x)
return output
In this case the model has 4 conv layers for downsampling and 1 final fully connected layer associated to binary output (note the sigmoid activation).
We can test this model by simply passing an image and checking the model’s output:
1
2
3
4
5
# Test the CNN
fake_image = tf.random.uniform((1, 128, 128, 3), dtype=tf.float32)
net = CNN(name='simple_model')
output = net(x)
print(output) # probability
1
tf.Tensor([[0.50065225]], shape=(1, 1), dtype=float32)
In order to check the correctness of the name scoping we can always print how some variables may look like when debugging. For example, here I want to check if my last layer follows the appropriate hierarchy (model_name/name_of_the_layer/name_of_the_weight):
1
2
output_variables = [var for var in net.trainable_variables if 'output' in var.name]
print(output_variables)
1
2
3
4
5
6
7
8
9
[<tf.Variable 'simple_model/output/bias:0' shape=(1,) dtype=float32, numpy=array([0.], dtype=float32)>,
<tf.Variable 'simple_model/output/weights:0' shape=(16384, 1) dtype=float32, numpy=
array([[ 0.03065354],
[ 0.0149726 ],
[-0.02742667],
...,
[-0.01549608],
[ 0.01788269],
[ 0.05695942]], dtype=float32)>]
We finally have a model!.
Further steps
Once the final model is designed we can create a custom training pipeline. This involves using a training loop as in PyTorch where we need to define training and validation steps.
To write a custom training step we can use tf.GradientTape and decorate its function with @tf.function to speed up its computation. This tutorial in the official Tensorflow documentation shows pretty well how the low level training/validation loop logic works. The main difference in this case would be using the model we defined above instead of tf.keras.Model.
Additional steps might imply writing a summary to log the training metrics in Tensorboard (using tf.summary.create_file_writer) and save checkpoints with the help of a checkpoint manager (tf.train.Checkpoint and tf.train.CheckpointManager). I will create another blog post showing their usage when writing low level TF pipelines.
For now, this link serves as a example showing how to manage these custom training pipeline concepts (summaries and checkpoints) in some models written with tf.keras.Model for retina damage detection in OCT scans: Link
This is a link to the Google Colab to run all the code from this post: Link
